The Squier Sonic Stratocaster is ready to launch any musical adventure into warp speed, offering iconic Fender® style and inspiring tone for players at any stage. This Strat sports a slim and inviting “C”-shaped neck profile and a thin, lightweight body for optimal playing comfort while a trio of Squier single-coil pickups chime with crystal clarity for a wide variety of versatile tones. Further details of this model include a tremolo bridge for expressive vibrato effects, sealed-gear tuning machines for smooth, accurate tuning and durable chrome-plated hardware that is sure to catch the spotlight.
General
SERIES Squier Sonic
ORIENTATION Right-Hand
COLOR Ultraviolet
COUNTRY OF ORIGIN ID
Neck
NECK MATERIAL Maple
NECK FINISH Satin Urethane
NECK SHAPE "C" Shape
NECK CONSTRUCTION Bolt-On
FINGERBOARD RADIUS 9.5" (241 mm)
FINGERBOARD MATERIAL Indian Laurel
POSITION INLAYS Pearloid Dot
NUMBER OF FRETS 21
TRUSS ROD Single-Action
TRUSS ROD NUT 4 mm Hex
STRING NUT Synthetic Bone
NUT WIDTH 1.650" (42 mm)
NUT MATERIAL Synthetic Bone
Body
BODY Poplar
BODY FINISH Gloss Polyurethane
BODY SHAPE Stratocaster
BODY MATERIAL Poplar
Hardware
BRIDGE 6-Saddle Vintage-Style Synchronized Tremolo with Block Saddles
PICKGUARD 1-Ply White
CONTROL KNOBS White Plastic
SWITCH TIP White
HARDWARE FINISH Chrome
TUNING MACHINES Die-Cast Sealed
STRINGS Nickel Plated Steel (.009-.042 Gauges)
NECK PLATE 4-Bolt Squier
STRAP BUTTONS Vintage-Style
Electronics
BRIDGE PICKUP Ceramic Single-Coil
MIDDLE PICKUP Ceramic Single-Coil
NECK PICKUP Ceramic Single-Coil
PICKUP CONFIGURATION SSS
CONTROLS Master Volume, Tone 1. (Neck/Middle Pickups), Tone 2. (Bridge Pickup)
SWITCHING 5-Position Blade: Position 1. Bridge Pickup, Position 2. Bridge and Middle Pickup, Position 3. Middle Pickup, Position 4. Middle and Neck Pickup, Position 5. Neck Pickup
Measurements
DIMENSIONS 4.00x14.90x44.40 IN
FRET SIZE Narrow Tall
SCALE LENGTH 25.5" (64.77 cm)
